GS-LI/D Low-intensity Double Aviation Obstruction

Written By Distributor Lampu Philips PT Savont Varavi IND on Selasa, 05 Juni 2018 | 18.42

GS-LI/D Low-intensity Double Aviation Obstruction ,Base with high intensity aviation aluminum casting,Fully sealed structure ;Light source

adopt with independent research and development dedicated LED chip ,which have the specific of low

power consumption and long long life ;Lampshade adopt with PC material ,it can resist corrosion ,

anti-UV ,anti-shock ;management circuit with Strong lightning protection and With the

surge protection device,which can adapt to extremity bad working environment .

This lamp with photoswich ,it can turn on when light intensity less than 50LUX,

and turn off when above 50Lux.

Features

Stainless steel baked with the lacquer base.
Special LED chips, with brightness, low energy consumption and long life.
PC material cover, provides strong corrosion resistance, UV resistance, impact resistance.
With lightning protection ability and control circuit with anti surge protective device that can apply to poor working environment.
With light-operated switch. When under the condition of less than 50Lux light, it can automatically switch ON the light, and if it under the conditions of over 50Lux light, it can automatically switch OFF.

Attention/ Usage Tips

Check whether the supply voltage does comply with the rated voltage of device.
Donot open it if the device is out of operation, in order not to be hurt by the internal high pressure.
After finished the installation, the personnel must check whether the device is in a good waterproof processing and

whether the screw spikes are tight

4.Non-professional workers can not do the device maintenance, in order not to expand the error and be hurt.

Name	Parameter
FAA Classify	L-810
Type	GS-LI/D
Power Supply	Optional voltage: AC220V, AC120V, DC12V, DC24V, DC48V
Power Supply Frequency	50HZ～60HZ
Average Power Consumption	≤3W
Working Mode	Optional: steady burning, flashing, steady burning backup, flash alternately
Light Intensity	Type B ≥32.5cd Type A ≥10cd
Horizontal Out-put	360°
Vertical Divergence	10°
Light Source service Life	≥20 years
Emitting Color	Red
Overall Size	285mm×136mm×320mm
Installation Size	3/4inches or 1 inch
IP Protection	IP65
Optical Ambient Brightness	50/100Lux
Ambient Temperature	-40℃～70℃
Weight	3kg
Anti-Wind Ability	120m/s
